Alveolar ridge

The alveolar ridge is the bony ridge within the maxilla and mandible that houses the tooth sockets (alveoli). It forms the primary support for the teeth, providing attachment for periodontal ligaments and surrounding gingiva. The ridge consists of compact cortical bone on the outer surface and trabecular bone internally, which contains the vascular and marrow components necessary for tooth health. The maxillary alveolar ridge is generally broader and less dense than the mandibular counterpart, while the mandibular ridge is denser and often more prominent. The alveolar ridge is continuous along the dental arch, from the anterior incisors to the posterior molars, and its height, width, and contour are critical for dentition alignment, prosthodontics, and dental implant placement.

Synonyms

  • Dental ridge

  • Jaw alveolar crest

  • Tooth-bearing ridge

Function

  • Provides support and anchorage for teeth

  • Serves as attachment for periodontal ligaments and gingiva

  • Maintains alveolar bone height and dental arch contour

  • Plays a role in mastication, speech, and facial aesthetics

MRI Appearance
T1-weighted images:

  • The alveolar ridge appears as a linear hypointense bony structure

  • Surrounding soft tissue and marrow show intermediate signal, with fatty marrow appearing hyperintense

  • Tooth roots appear low signal, while dental pulp may show intermediate signal

  • Fractures, cysts, or tumors appear as disruption or replacement of normal low-signal bone

T2-weighted images:

  • Cortical bone of the ridge is very low signal

  • Trabecular bone marrow appears intermediate to hyperintense, depending on marrow fat content

  • Pathology such as edema, infection, or cystic lesions appears hyperintense, facilitating detection

STIR (Short Tau Inversion Recovery):

  • Suppresses fat signal, highlighting bone marrow edema, osteomyelitis, or early cystic lesions

  • Normal alveolar ridge cortical bone remains low signal, while pathologic changes appear bright

CT Appearance

  • Appears as a well-defined bony ridge, with cortical bone hyperdense and trabecular bone slightly less dense

  • Tooth sockets are clearly visible as hypodense cavities within the ridge

  • Surrounding air in the oral cavity appears hypodense, providing contrast to bone

  • CT is ideal for evaluating bone height, cortical integrity, fractures, cysts, tumors, or planning dental implants

MRI images

Alveolar Ridge mri sagittal image -img-00000-00000
