Body of the Metacarpal Bone: Anatomy, Structure, Function, Imaging

Topic

Body of metacarpal bone

The body (shaft) of the metacarpal bone forms the elongated central portion of each metacarpal, extending between the base and the head. It serves as the structural framework of the hand, supporting the palm and providing attachment sites for muscles, tendons, and ligaments that facilitate grip and digital motion.

Each metacarpal bone consists of a base (proximal end), shaft (body), and head (distal end). The body is slightly curved—concave on the palmar surface and convex dorsally, optimizing the shape of the palm and ensuring an efficient grasp. The cortical bone is thick dorsally and laterally, giving it strength while allowing a degree of torsional flexibility.

Synonyms

Shaft of metacarpal bone
Diaphysis of metacarpal
Metacarpal midportion

Structure and Location

Shape: Slightly curved longitudinally; prismatic cross-section with dorsal convexity and palmar concavity.
Surfaces:
- Dorsal surface: Smooth and convex, providing attachment for extensor tendons.
- Palmar surface: Concave, allowing space for flexor tendons and palmar interossei.
Borders:
- Medial and lateral borders serve as attachment lines for interosseous muscles.
Composition: Thick cortical bone surrounding cancellous marrow.
Bone type: Long bone with a diaphysis containing red or yellow marrow depending on age and hand dominance.

Relations

Dorsally: Extensor tendons, dorsal interosseous muscles, and subcutaneous fascia
Palmar (volar) surface: Flexor tendons, lumbrical and palmar interosseous muscles
Laterally and medially: Adjacent metacarpal shafts and interosseous membranes or muscles
Proximally: Base articulates with carpal bones and adjacent metacarpal bases
Distally: Head articulates with the base of the proximal phalanx

Attachments

Muscles:
- Dorsal interossei: Originate from adjacent sides of metacarpal bodies.
- Palmar interossei: Arise from the sides of metacarpals of digits 2, 4, and 5.
- Lumbricals: Originate from flexor digitorum profundus tendons that course along the palmar aspect near the metacarpal shafts.
Ligaments:
- Deep transverse metacarpal ligament connects adjacent metacarpal heads.
- Dorsal and palmar carpometacarpal ligaments stabilize the bases.

Function

Structural support: Forms the skeletal framework of the palm.
Load transmission: Transfers forces between the wrist and fingers during grip and movement.
Attachment site: Provides origin and insertion for intrinsic hand muscles.
Flexibility and mobility: Slight curvature and elasticity allow the palm to cup and flatten for grasping.
Protection: Shields tendons, vessels, and nerves of the palm.

Clinical Significance

Fractures: Commonly occur in the metacarpal body due to direct trauma, punching injuries, or crush forces (“boxer’s fracture” typically affects the 5th metacarpal).
Malalignment: Angulation or rotation deformities can severely impact hand function.
Stress fractures: Seen in athletes, laborers, or those with repetitive load-bearing activities.
Infection (osteomyelitis): May follow open fractures or puncture wounds.
Tumors and cysts: Benign lesions such as enchondromas may expand the shaft.
Imaging role: MRI and CT vital for assessing cortical disruption, marrow pathology, and fracture healing.

MRI Appearance

T1-weighted images:
- Cortex: Low signal (dark), sharply marginated.
- Bone marrow: Bright, reflecting fatty marrow signal.
- Periosteum: Thin low-signal line surrounding the cortex.
- Pathology: Fracture lines appear as linear low-signal areas crossing the marrow; marrow edema shows intermediate-to-bright signal.
T2-weighted images:
- Cortex: Persistently dark (low signal).
- Bone marrow: Bright, slightly less intense than on T1 but higher than muscle.
- Edema or inflammation: Hyperintense signal within medullary cavity or periosteum.
- Cartilage at articulations: Intermediate-to-bright thin layer at proximal and distal ends.
STIR:
- Normal marrow: Intermediate-to-dark signal.
- Abnormal marrow: Bright hyperintense in bone contusion, edema, or infection.
- Periosteal reaction or soft-tissue swelling: Also hyperintense on STIR.
Proton Density Fat-Saturated (PD FS):
- Normal marrow: Intermediate-to-dark homogeneous signal.
- Pathologic marrow: Bright hyperintensity representing edema, fracture, or tumor infiltration.
- Excellent sequence for detecting subtle stress fractures and soft-tissue edema.
T1 Fat-Sat Post-Contrast:
- Normal bone: Mild homogeneous enhancement due to vascularized marrow.
- Infection or inflammation: Patchy or irregular marrow enhancement with surrounding soft-tissue hyperemia.
- Neoplasm: Focal or diffuse enhancement depending on lesion type.
- Post-traumatic granulation: Peripheral rim enhancement at fracture margins.

CT Appearance

Non-Contrast CT:

Cortex: High attenuation, sharply outlined dense structure.
Trabecular bone: Fine, regular lattice pattern.
Marrow cavity: Uniform low attenuation (fat).
Pathology: Detects fractures, cortical irregularities, osteolysis, periosteal reaction, and sclerosis.
Particularly useful for:
- Subtle fracture lines not visible on X-ray.
- Assessment of alignment and bone healing.
- Pre-surgical planning for fixation.

CT VRT 3D image

MRI image

CT image
