Flexor retinaculum

The flexor retinaculum is a strong fibrous band forming the roof of the tarsal tunnel on the medial side of the ankle. It extends from the medial malleolus of the tibia to the medial aspect of the calcaneus, holding the tendons of the deep flexor muscles in place and protecting the neurovascular structures of the tarsal tunnel.

It serves as a stabilizing structure for the tendons of tibialis posterior, flexor digitorum longus, and flexor hallucis longus, as well as the posterior tibial vessels and tibial nerve. Thickening or fibrosis of the retinaculum may compress these structures, resulting in tarsal tunnel syndrome.

Synonyms

  • Laciniate ligament

  • Internal annular ligament

  • Medial ankle retinaculum

Origin, Course, and Insertion

  • Origin: Medial malleolus of the tibia and the lower part of the posterior surface of the tibia

  • Course: Extends obliquely downward and backward over the tarsal tunnel; forms the roof of the tunnel containing tendons and neurovascular structures enclosed in synovial sheaths

  • Insertion: Medial aspect of the calcaneus and plantar aponeurosis

Relations

  • Superiorly: Posterior surface of the medial malleolus and distal tibia

  • Inferiorly: Medial surface of the calcaneus

  • Anteriorly: Skin and superficial fascia of the medial ankle

  • Posteriorly: Deep fascia covering flexor hallucis longus and posterior tibial tendons

  • Deep to it: (From anterior to posterior — “Tom, Dick And Very Nervous Harry”)

    • Tibialis posterior tendon

    • Flexor digitorum longus tendon

    • Posterior tibial artery

    • Posterior tibial vein

    • Tibial nerve

    • Flexor hallucis longus tendon

Function

  • Retention of tendons: Prevents bowstringing of the deep flexor tendons during plantar flexion

  • Protection: Shields tendons, vessels, and nerves from friction and external trauma

  • Structural support: Forms the roof of the tarsal tunnel, maintaining the integrity of its contents

  • Facilitation of movement: Allows smooth gliding of tendons in synovial sheaths during foot motion

Clinical Significance

  • Tarsal tunnel syndrome: Compression of the tibial nerve beneath the retinaculum leading to pain, paresthesia, or numbness along the plantar surface of the foot

  • Thickening or fibrosis: May occur due to trauma, overuse, or inflammatory conditions (e.g., rheumatoid arthritis)

  • Traumatic injury: Avulsion or tearing can occur with ankle sprains or fractures, causing instability of flexor tendons

  • Post-surgical scarring: May result in recurrent compression symptoms after decompression procedures

  • Imaging role: MRI is key in assessing thickening, space-occupying lesions, and inflammatory changes within the tarsal tunnel

MRI Appearance

  • T1-weighted images:

    • Retinaculum: low signal intensity (dark fibrous band) overlying the tarsal tunnel

    • Tendons beneath: intermediate-to-low signal

    • Adjacent fat planes: bright, aiding delineation of the retinaculum

    • Thickening or fibrosis: intermediate signal relative to normal low-signal retinaculum

  • T2-weighted images:

    • Normal retinaculum: dark (low signal) compared to muscle

    • Pathology: thickened or fibrotic retinaculum may show mildly increased intermediate signal

    • Tarsal tunnel pathology: edema, ganglion cysts, or nerve swelling show bright hyperintense signal beneath the retinaculum

  • STIR:

    • Normal: dark fibrous band

    • Pathologic thickening or inflammation: hyperintense signal within or around the retinaculum

    • Nerve edema or entrapment: bright linear or fusiform signal posterior to the medial malleolus

  • Proton Density Fat-Saturated (PD FS):

    • Normal retinaculum: uniform dark band with clear margins

    • Abnormal: bright peritendinous or perineural signal from inflammation or fluid collection

    • Excellent for identifying tarsal tunnel fluid, synovitis, or tendon sheath effusions

  • T1 Fat-Sat Post-Contrast:

    • Normal: no significant enhancement

    • Pathologic: enhancement of thickened retinaculum, inflamed tendon sheaths, or nerve irritation

    • Helpful for distinguishing post-traumatic scarring from normal fibrous bands

CT Appearance

Non-Contrast CT:

  • Retinaculum: thin soft-tissue density band overlying the medial ankle

  • Not well visualized unless thickened or calcified

  • May show bony irregularities of the medial malleolus or calcaneus related to chronic traction

  • Indirect signs: soft-tissue swelling or tunnel narrowing

Post-Contrast CT (standard):

  • Normal: minimal enhancement

  • Abnormal: mild enhancement in inflamed or thickened retinaculum

  • Useful to assess calcification, foreign bodies, or postsurgical fibrosis causing compression

MRI image

Flexor retinaculum coronal cross sectional anatomy 3T MRI AI enhanced radiology image-img-00000-00000

MRI image

Flexor retinaculum axial cross sectional anatomy 3T MRI AI enhanced radiology image-img-00000-00000

CT image

Flexor retinaculum ct axial image
