Internal carotid artery (petrous part)

The petrous part of the internal carotid artery (ICA) is a key segment of the ICA as it traverses the petrous temporal bone within the carotid canal. It plays a critical role in supplying blood to the brain, especially the anterior and middle cerebral circulations. Understanding its anatomy, function, and imaging characteristics is essential in diagnosing vascular, neoplastic, and traumatic lesions involving the skull base.

Synonyms

  • Petrous ICA

  • Petrous segment of the internal carotid artery

  • Carotid canal segment

  • Petrosal part of the ICA

Function

  • Transmits oxygenated blood from the common carotid bifurcation to the cavernous and intracranial ICA segments

  • Supplies small branches to the surrounding temporal bone, tympanic cavity, and adjacent neural structures

  • Provides vital circulation to the brain, especially in cases of collateral flow or vascular compromise

MRI Appearance

  • T1-Weighted Images:

    • Appears as a flow void (signal loss) due to rapid blood flow within the lumen

    • Surrounded by hyperintense bone marrow and hypointense cortical bone of the petrous temporal bone

  • T2-Weighted Images:

    • Also shows a flow void (dark signal) within the vessel

    • Adjacent petrous bone appears dark; any abnormal signal within the artery may suggest slow flow or thrombosis

  • STIR (Short Tau Inversion Recovery):

    • Flow void in the vessel; background fat suppression may accentuate the artery as a dark structure

    • Hyperintense signal around the ICA may suggest edema, inflammation, or tumor

  • TOF (Time-of-Flight) MR Angiography:

    • ICA appears as a bright, high-signal tubular structure within the petrous canal

    • Useful for non-contrast evaluation of vessel patency, stenosis, or dissection

CT Appearance

  • Petrous ICA is seen as a round or oval soft-tissue density structure within the carotid canal of the petrous bone

  • The surrounding bony canal is well visualized on bone window settings

  • Can identify bony erosions, fractures, or aberrant course

CTA (CT Angiography) Appearance

  • Enhanced, well-opacified vessel within the petrous carotid canal

  • Can assess vessel lumen for stenosis, dissection, aneurysms, or abnormal enhancement

MRI images

Internal carotid artery (petrous part) coronal image

MRI images

Internal carotid artery (petrous part) mri axial image
