Mastoid process

The mastoid process is a prominent, conical bony projection located on the posteroinferior aspect of the temporal bone, just behind the ear. It contains air cells that communicate with the middle ear and plays a crucial role in the structural integrity of the skull and the attachment of several neck muscles. The mastoid process is clinically important in otology, head and neck surgery, and radiology, particularly in the context of mastoiditis, trauma, or neoplastic conditions.

Synonyms

  • Mastoid part of temporal bone

  • Processus mastoideus (Latin)

  • Mastoid air cells (when referring to the cellular structure within)

MRI Appearance of the Mastoid Process

1. Proton Density (PD) Sequence

  • Mastoid cortex appears as a low signal intensity (dark) margin, indicating dense cortical bone.

  • Mastoid air cells demonstrate low signal intensity (black) due to the presence of air.

  • Any fluid or soft tissue within the mastoid air cells appears as intermediate to high signal.

  • Useful for differentiating air-filled spaces from fluid or pathology within the mastoid.

2. Short Tau Inversion Recovery (STIR)

  • Normal mastoid air cells remain low signal (black).

  • High signal (bright) within mastoid air cells suggests abnormal fluid, edema, or inflammation, such as mastoiditis.

  • Cortical bone remains low signal (dark).

  • STIR sequence is highly sensitive to fluid and marrow edema, making it valuable for detecting infection or infiltration.

3. T1-Weighted Sequence

  • Cortical bone of the mastoid process is low signal (dark).

  • Normal mastoid air cells are also very low signal (black) due to air content.

  • Fluid, pus, or soft tissue pathology within the air cells appear as low to intermediate signal, depending on the protein content.

  • High signal within the mastoid process on T1 is unusual and may indicate hemorrhage or high-protein content fluid.

MRI images

Mastoid process mri image

CT VRT 3D image

Mastoid process 3d

X ray image

X rayMastoid process anatomy image -img-00000-00000
