Olecranon fossa

The olecranon fossa is a deep triangular depression located on the posterior aspect of the distal humerus, just above the trochlea. It accommodates the olecranon process of the ulna during elbow extension, preventing bony impingement and allowing smooth motion.

This fossa plays a critical role in elbow kinematics, providing space for the olecranon when the joint is fully extended. It contributes to the stability and congruency of the elbow joint by complementing the shape of the olecranon process and trochlea.

Synonyms

Posterior humeral fossa
Olecranon depression of humerus

Location and Structure

Situated on the posterior distal humerus, superior to the trochlea.
Shape: Deep, triangular depression with smooth walls.
Boundaries:
- Superiorly: Shaft of humerus
- Inferiorly: Trochlea
- Laterally and medially: Bounded by medial and lateral supracondylar ridges
Articular connection: During extension, the olecranon process of the ulna fits snugly into the fossa.
The floor is thin, separating the fossa from the coronoid fossa on the anterior surface by a narrow bony septum, which may be perforated in some individuals (supratrochlear foramen).

Relations

Posteriorly: Triceps brachii tendon and overlying subcutaneous tissue
Anteriorly: Coronoid fossa and trochlea of the humerus (separated by thin bony plate)
Superiorly: Humeral shaft and periosteum
Inferiorly: Elbow joint capsule and trochlea
Medially and laterally: Medial and lateral epicondyles

Function

Joint accommodation: Receives the olecranon process during full extension of the elbow, preventing impingement.
Joint stability: Enhances bony congruence between the humerus and ulna.
Range of motion: Permits full elbow extension without restricting movement.
Load distribution: Helps transmit mechanical stresses between humerus and ulna during arm extension.

Clinical Significance

Fractures: Olecranon fossa can be involved in distal humeral fractures, particularly in supracondylar and intercondylar patterns.
Osteophyte formation: Chronic stress or arthritis may cause bony spurs within the fossa, leading to olecranon impingement syndrome.
Supratrochlear foramen: Thin or perforated septum between olecranon and coronoid fossae may appear radiolucent on X-ray — a normal variant, not a pathology.
Arthritis: Degenerative changes may reduce fossa depth, limiting elbow extension.
Post-traumatic deformity: Malunited distal humerus fractures can alter the fossa’s contour and joint mechanics.
Imaging relevance: MRI and CT play vital roles in evaluating fractures, impingement, degenerative changes, and bone marrow pathology.

MRI Appearance

T1-weighted images:
- Cortex: Low signal (dark) outlining the fossa margins.
- Marrow: Bright signal due to fatty content in the distal humerus.
- Fossa cavity: Appears as a low-signal void filled with joint fluid or synovium.
- Pathology: Fractures show low-signal cortical disruption; marrow edema appears intermediate-to-bright.
T2-weighted images:
- Cortex: Low signal (dark).
- Marrow: Bright signal (less than T1 but still hyperintense relative to muscle).
- Joint fluid: Hyperintense, filling the fossa in extended positions.
- Osteophytes or sclerosis: Low-signal foci along margins.
- Pathology: Effusions, synovial hypertrophy, or cystic changes show bright hyperintense signal.
STIR:
- Normal marrow: Intermediate-to-dark signal.
- Pathology: Bright hyperintense signal in edema, contusion, or inflammatory changes.
- Excellent for detecting subtle marrow injury in occult humeral fractures.
Proton Density Fat-Saturated (PD FS):
- Normal bone: Intermediate-to-dark signal.
- Pathologic areas: Bright hyperintensity indicating edema or bone stress reaction.
- Highlights joint fluid and pericapsular inflammation with high sensitivity.
T1 Fat-Sat Post-Contrast:
- Normal bone: Mild homogeneous enhancement.
- Inflammation or arthritis: Enhancing synovium or bone marrow.
- Fractures: Peripheral enhancement around low-signal fracture line.
- Osteomyelitis: Irregular marrow enhancement with cortical involvement.

CT Appearance

Non-Contrast CT:

Cortex: High attenuation with clear concave fossa margins.
Marrow: Homogeneous intermediate density.
Fossa cavity: Radiolucent space corresponding to olecranon accommodation area.
Pathology:
- Detects small fracture lines, osteophytes, or cortical thinning.
- Supratrochlear foramen appears as a distinct low-density perforation.
- Useful for evaluating post-traumatic deformities and osteochondral defects.

Post-Contrast CT (standard):

Normal: Bone cortex and marrow show uniform enhancement.
Inflammation: Enhancing synovium or pericapsular tissues.
Osteomyelitis: Heterogeneous enhancement with cortical irregularity or lytic foci.
Postoperative evaluation: Assesses callus formation and implant position.

CT VRT 3D image

MRI image

CT image
