Olfactory trigone

he olfactory trigone is a small, triangular cortical area located at the base of the frontal lobe, forming part of the olfactory system. It represents the posterior expansion of the olfactory tract, where fibers diverge into the medial and lateral olfactory striae. The region serves as a crucial relay zone for olfactory information processing, connecting the olfactory bulb and tract with cortical centers responsible for smell perception and emotional association.

It lies at the junction of the olfactory sulcus and the anterior perforated substance, forming the anterior part of the olfactory cortex. The olfactory trigone also participates in limbic and autonomic pathways, linking olfactory input to memory, appetite, and behavior.

Synonyms

  • Trigonum olfactorium

  • Olfactory area of the frontal lobe

  • Anterior olfactory cortex

Location and Structure

  • Anatomical position: Situated at the anterior end of the anterior perforated substance, in the basal frontal region.

  • Boundaries:

    • Anteriorly: Olfactory tract

    • Posteriorly: Anterior perforated substance

    • Medially: Gyrus rectus

    • Laterally: Orbital gyrus

  • Shape: Small triangular gray matter region forming a flattened area between the olfactory tract and basal forebrain.

  • Composition: Contains cortical neurons involved in primary olfactory processing and fibers connecting to olfactory striae.

Function

  • Olfactory integration: Receives olfactory impulses from the olfactory tract and distributes them to the olfactory striae for higher cortical processing.

  • Medial olfactory stria: Projects to limbic structures (septal area, hypothalamus) — involved in autonomic and emotional responses to odors.

  • Lateral olfactory stria: Projects to the primary olfactory cortex (piriform area, amygdala) — responsible for conscious odor perception.

  • Behavioral modulation: Links olfactory cues to memory, appetite, and social-emotional reactions.

Clinical Significance

  • Lesions: Rarely isolated, but damage can result from trauma, tumors, or anterior cerebral artery aneurysms, causing anosmia (loss of smell).

  • Olfactory groove meningioma: May compress the olfactory trigone, resulting in olfactory loss and frontal lobe dysfunction.

  • Neurodegenerative diseases: Early involvement in Parkinson’s and Alzheimer’s disease leads to smell impairment.

  • Surgical importance: Important landmark in basal frontal and subfrontal surgical approaches.

  • Epilepsy: Focal cortical dysplasia or gliosis in this region may act as an epileptogenic focus.

MRI Appearance

T1-weighted images:

  • Gray matter: Intermediate signal intensity.

  • White matter: Brighter signal compared to cortex.

  • CSF in adjacent cisterns: Dark (low signal).

  • Olfactory tract and trigone: Seen as a narrow intermediate-gray structure anterior to the anterior perforated substance.

  • Pathology:

    • Meningiomas appear as isointense-to-slightly-hypointense masses with mass effect on the trigone.

    • Gliosis or atrophy presents as volume loss and sulcal widening.

T2-weighted images:

  • Gray matter: Intermediate-to-bright signal.

  • White matter: Slightly darker than cortex.

  • CSF: Very bright.

  • Pathology:

    • Tumors: Heterogeneous or bright signal depending on lesion type.

    • Edema or encephalitis: Bright hyperintense signal in surrounding basal frontal regions.

    • Infarction: Hyperintense cortical/subcortical change with loss of definition of the trigone.

FLAIR:

  • Normal trigone: Intermediate gray signal surrounded by dark CSF.

  • Pathology:

    • Gliosis, inflammation, or infarction appear as bright hyperintense foci extending into the anterior perforated substance.

    • Meningiomas may compress or displace the trigone, seen as adjacent bright perilesional signal.

    • Neurodegenerative atrophy: Subtle widening of basal frontal sulci with hyperintense cortical margins.

DWI (Diffusion-Weighted Imaging):

  • Normal trigone: Isointense to surrounding cortex.

  • Acute infarction: Bright restricted diffusion with corresponding ADC hypointensity.

  • High-grade tumors: May show variable diffusion restriction depending on cellularity.

  • Encephalitis or abscess: Restricted diffusion with adjacent edema.

T1 Fat-Sat Post-Contrast:

  • Normal trigone: Minimal enhancement of cortical surface.

  • Meningioma: Strong, homogeneous enhancement with dural attachment in olfactory groove region.

  • Glioma or metastasis: Patchy or ring-like enhancement with surrounding edema.

  • Inflammatory lesions: Mild to moderate cortical and subcortical enhancement.

CT Appearance

Non-Contrast CT:

  • Gray matter: Intermediate density.

  • White matter: Slightly hypodense compared to cortex.

  • CSF: Hypodense.

  • Olfactory trigone: Not distinctly visualized but inferred as the gray matter region anterior to the anterior perforated substance.

MRI image

Olfactory trigone-img-00000-00000

MRI image

Olfactory trigone axial
