Renal vein

The renal veins are paired large vessels that drain blood from the kidneys into the inferior vena cava (IVC). The right renal vein is shorter and drains directly into the IVC, while the left renal vein is longer, passing anterior to the aorta and posterior to the superior mesenteric artery (SMA) before entering the IVC.

The renal veins collect blood from the interlobar, arcuate, and interlobular veins, converging at the renal hilum. The left renal vein receives additional tributaries, including the left gonadal vein, left adrenal vein, and left inferior phrenic vein.

Anatomical variants are common, such as retroaortic left renal vein (coursing posterior to the aorta), circumaortic renal vein (duplicated anterior and posterior channels), and multiple renal veins draining separately into the IVC. These are clinically important in surgery, transplantation, and venous pathology.

Synonyms

  • Vena renalis

  • Kidney vein

  • Left and right renal veins

Function

  • Drain deoxygenated blood from the kidneys into the IVC

  • Maintain renal venous pressure equilibrium

  • Provide collateral venous pathways in case of IVC obstruction

  • Serve as key landmarks in urologic, vascular, and transplant surgery

Variants

  • Retroaortic left renal vein – passes behind the aorta before draining into IVC

  • Circumaortic left renal vein – dual anterior and posterior venous channels around the aorta

  • Multiple renal veins – common on the right side, draining separately into IVC

  • Anomalous tributaries – variations in gonadal or adrenal vein entry

MRI Appearance

T1-weighted images:

  • Renal veins appear as flow voids (black lumens) within perinephric fat

  • Left renal vein is easily visualized crossing anterior to the aorta

T2-weighted images:

  • Veins appear as dark signal flow voids, contrasted against bright surrounding fat

  • Thrombosis may appear as intermediate to high intraluminal signal

STIR:

  • Suppresses fat, making veins and thrombus more conspicuous

  • Useful for identifying peri-venous edema, inflammation, or tumor invasion

T1 Fat-Saturated (Pre-contrast):

  • Lumen often shows intermediate signal, contrasting with suppressed fat

  • Highlights the venous course, especially in hilum and retroperitoneum

T1 Fat-Saturated Post-Contrast (Gadolinium):

  • Veins enhance brightly and homogeneously during venous phase

  • Detects renal vein thrombosis, tumor thrombus, and anomalous drainage

MRV (Magnetic Resonance Venography):

  • Excellent for mapping renal vein anatomy and variants

  • Demonstrates retroaortic, circumaortic, or multiple renal veins

  • Useful for renal transplant donor evaluation and venous thrombosis

CT Appearance

CT Pre-Contrast:

  • Renal veins visible as soft-tissue tubular densities in perinephric fat

  • May show hyperdense thrombus in acute renal vein thrombosis

CT Post-Contrast (Venous Phase):

  • Renal veins opacify brightly, clearly delineating course and tributaries

  • Detects thrombosis, extrinsic compression, or tumor extension

  • Useful for staging renal cell carcinoma with venous invasion

CT Venography (CTV):

  • Provides high-resolution mapping of renal vein anatomy and variants

  • Defines precise relationship of renal veins to IVC and aorta

  • Essential for transplant surgery, IVC filter placement, and venous occlusion planning

CT images

Renal vein CT AXIAL image anatomy image -img-00000-00000

CT images

Renal vein CT AXIAL image anatomy image -img-00000-00000_00001

MRI images

Renal vein MRI coronal image anatomy image -img-00000-00000

MRI images

Renal vein MRI coronal image anatomy image -img-00000-00000_00001

MRI images

Renal vein MRI coronal image anatomy image -img-00000-00000_00002
