Temporal bone

The temporal bone is a paired, complex bone forming the lateral aspect and base of the skull. It houses critical structures related to hearing, balance, facial nerve function, and forms part of the cranial vault, cranial base, and temporomandibular joint. Due to its intricate anatomy and multiple components, the temporal bone is of major importance in neuroanatomy, otology, neuroradiology, and skull base surgery.

It contains air-filled spaces, dense petrous bone, neurovascular canals, and articulations that are frequently evaluated on high-resolution imaging.

Synonyms

  • Temporal cranial bone

  • Os temporale

Location

  • Located on the inferolateral aspect of the skull

  • Forms part of the lateral cranial vault and skull base

  • Situated inferior to the parietal bone

  • Posterior to the sphenoid bone

  • Anterior to the occipital bone

  • Lateral to the middle and posterior cranial fossae

Anatomical parts

  • Squamous part:

    • Thin, flat portion forming the lateral skull wall

  • Petrous part:

    • Dense, pyramid-shaped portion housing the inner ear

  • Mastoid part:

    • Posteroinferior portion containing mastoid air cells

  • Tympanic part:

    • Forms the anterior and inferior walls of the external auditory canal

  • Styloid process:

    • Slender bony projection for muscular and ligamentous attachment

Major landmarks and contents

  • External auditory canal

  • Middle ear cavity

  • Inner ear (cochlea, vestibule, semicircular canals)

  • Facial nerve canal

  • Internal auditory canal

  • Carotid canal

  • Jugular fossa (contributes to jugular foramen)

  • Mandibular (glenoid) fossa

Relations

Superiorly:

  • Parietal bone

  • Middle cranial fossa contents (temporal lobe)

Inferiorly:

  • Neck soft tissues

  • Stylohyoid region

Anteriorly:

  • Sphenoid bone

  • Temporomandibular joint

Posteriorly:

  • Occipital bone

  • Posterior cranial fossa

Medially:

  • Brainstem and cerebellum (via petrous part)

Laterally:

  • Scalp and external ear

Developmental anatomy

  • Develops from multiple ossification centers

  • Squamous and tympanic parts: Intramembranous ossification

  • Petrous and mastoid parts: Endochondral ossification

  • Mastoid air cells: Develop postnatally and pneumatize with age

X-ray appearance

Skull radiographs (lateral / oblique views):

  • Squamous temporal bone: Thin cortical outline

  • Mastoid air cells: Radiolucent honeycomb appearance

  • Petrous ridge: Dense radiopaque structure

  • External auditory canal: Circular radiolucency

CT appearance

Non-contrast CT:

  • Bone detail: Excellent delineation of cortical and trabecular bone

  • Petrous part: Very high density

  • Mastoid air cells: Well-defined air-filled spaces

  • Middle and inner ear structures: Clearly visualized on high-resolution CT

Post-contrast CT:

  • Bone: No enhancement

  • Vascular structures: Enhancement within carotid canal and jugular bulb

  • Soft tissues: Evaluated for adjacent inflammatory or neoplastic processes

3D CT VRT appearance

Volume-rendered technique (VRT):

  • Temporal bone contours: Complex surface anatomy well demonstrated

  • Zygomatic process and mastoid region: Clearly visualized

  • Styloid process: Well-defined elongated projection

  • Clinical utility: Useful for surgical planning, trauma assessment, and congenital anomalies

MRI appearance

T1-weighted images:

  • Cortical bone: Low signal intensity

  • Petrous marrow (variable): Intermediate signal depending on fatty content

  • Inner ear fluid: Low signal

  • Cranial nerves (IAC): Identifiable as linear structures

T2-weighted images:

  • Inner ear fluid: High signal (endolymph and perilymph)

  • Air-filled spaces: Signal voids

  • Brain parenchyma: Normal adjacent temporal lobe signal

CT VRT 3D image

Temporal bone 3d

X-Ray image

X ray Temporal bone anatomy image -img-00000-00000
